TDS Meter V1.0 Water Quality Sensor

TDS sensor kit is compatible with Arduino controllers, plug and play, and easy to use.
It can be applied to measure the TDS value of the water, to reflect the cleanliness of the water.
TDS (Total Dissolved Solids) indicates how many milligrams of soluble solids are dissolved in one liter of water. In general, the higher the TDS value, the more soluble solids dissolved in water, and the less clean the water is.
Therefore, the TDS value can be used as one of the references for reflecting the cleanliness of water
Measuring the TDS value in the water is to measure the total amount of various organic or inorganic substances dissolved in water, in the unit of ppm or milligrams per liter (mg/l).

Technical Parameters

TDS Meter:

• Input Voltage: DC 3.3 ~ 5.5V
• Output Voltage: 0 ~ 2.3V
• Working Current: 3 ~ 6mA
• TDS Measurement Range: 0 ~ 1000ppm
• TDS Measurement Accuracy: ± 10% F.S. (25 ℃)
• Module Interface: XH2.54-3P
• Electrode Interface: XH2.54-2P

TDS Probe:

• Number of Needles: 2
• Total Length: 60cm
• Connection Interface: XH2.54-2P
• Color: White
• Other: Waterproof Probe
